Raymond Grinder

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1467546

• Place of Origin:

  China
• Raymond Mill is Raymond Grinder applicable to the grinding and processing of more than 280 kinds of non-flammable and non-explosive materials with hardness less than 7 and humidity less than 6% in mining, construction, chemical industry and metallurgy, such as barite, calcite, feldspar, talcum, marble, limestone, clay, glass. The fineness of the finished product can be adjusted from 100 mesh to 325 mesh according to the customers requirements.
  Working Principle:
  Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.
  Structural characteristics :
  1.the whole grinding mill is of a standing structure. It features small occupying space and strong integration capacity. It can form an independent production system from the lump materials , crushing to finished powder and packaging.
  2. All the finished particles have a good uniformity of fineness, with passing screen rate as high as 98%. This is what other machine cannot reach.
  3.The machine adopts electromagnetic vibrating feeder, which ensures even and regular feeding.
  4.It is easy to adjust, small in dimension, light in weight, with lower oil and power consumption and easy to maintain.
